If it’s a present for a loved one, they’ll definitely want to choose this! But if it’s just for themselves, they’ll probably ignore this option.Īgain, it’s really simple to do this in Gleek. Our online store is going to offer the customer the option to choose gift wrapping. Because our first fragment is optional, we’ll use the opt label. You can read a lot more about these in our detailed blog post about sequence diagram fragments, but for now you just need to know that this optional case will be shown as a rectangular frame over the diagram, with a label in the top left. Now we’re going to tackle a simple conditional case. Lots of other things are probably happening in the system that supports the online store, such as the shopping cart being updated in the database, the item count in inventory being changed, but we don’t need to worry about those for now. The user has added an item to the cart and that sends a message to the online store. You’ll notice that Gleek automatically creates a lifeline for each object and the message, or action, is transmitted from left to right. You just type a hyphen, add the text for the label, another hyphen and end with a chevron to create the arrow.Īnd here’s how it looks after Gleek has instantaneously converted the text into a diagram. In Gleek, you just type the name of each object and connect them with a labeled arrow to show the objects and the message being transmitted between them. We’ll need two objects – the user and the online store. The first step is to add an item to the shopping cart. Don’t forget that you can also create other types of diagrams, such as flowcharts and entity-relationship diagrams!īecause we’re modeling a sequence in time, we’ll dive straight in and start at the point where a customer has decided on their purchase. That will tell Gleek what kind of diagram you want to create, so that it will draw the elements correctly. So let’s get to it!įirst, open up the Gleek.io app and select sequence diagram from the dropdown. That makes this kind of system perfect for describing with a sequence diagram. Making a purchase online involves a lot of back and forth between the user, the store, the payment gateway, and even potentially a bank, if a transfer is involved. Step-by-step guide to creating a sequence diagram for an online shopping system You might even like to keep this open while you go through this guide.
Sequence diagram for banking system full#
Ĭheck out our detailed page on sequence diagrams for a full rundown on the elements and a pro cheat sheet for using Gleek syntax to create them. Make your own UML sequence diagram with Gleek.
These are shown in a special frame in the diagram and let you create complex alternative paths for the system. You can also model situations where one or more optional or alternative events take place. Each object has a lifeline that descends vertically and this lifeline will show an activation bar if the object is active. These messages are shown as arrows that can go both left and right. Objects are activated as messages travel back and forth on the horizontal axis. Sequence diagrams use a horizontal axis for the objects being modeled, with the vertical axis showing how time progresses from top to bottom.
Sequence diagram for banking system software#
Sequence diagrams help a software engineer or developer visualize the order in which events occur and how they trigger activity within the system. While some of these diagrams, such as class diagrams or object diagrams, are designed to show the static structure of a system, a sequence diagram shows how the system behaves over time and how the different parts of the system interact during that time frame.Ī sequence diagram captures messaging between objects in a system and indicates which object is active at any particular point in the process of carrying out operations. Sequence diagrams are one of the 14 different types of Unified Modeling Language (UML) diagrams. What is the purpose of sequence diagrams?
